Pci Express For Mac

Details about Desktop PCI Express 6 Ports SATA 3.0 4X 8X 16X Expansion card for Mac Windows7 8. Desktop PCI Express 6 Ports SATA 3.0 4X 8X 16X Expansion card for Mac Windows7 8. Item Information. 6 AHCI SATA III (6 Gbps) ports through PCI Express x4. Fully compliant with SATA 3.0 specifications and backward compatible with SATA I/II (1.5/3. Our PCI Express card is compatible with Apple's Mac Pro 2008-2012 towers. You can mount any 2.5' Mac compatible SATA III SSD onto this adapter card. By taking advantage of your Mac Pro's quicker PCI Express bus, you can substantially increase the access time over your conventional SATA II drive bays. The drive bays in a Mac Pro are limited to 275/255 Mbps read/write speeds. This adapter/drive.

The Mac Pro introduced in 2019 has eight PCIe slots:

Four double-wide slots
Three single-wide slots
One half-length slot preconfigured with the Apple I/O card

Mac Pro includes one or two Radeon Pro MPX Modules that occupy slots 1-2 and slots 3-4. You can choose your MPX Modules when you order your Mac Pro or order them separately from Apple. Learn how to install PCI cards in your Mac Pro (2019).

Apple AMD Radeon MPX Modules

Apple currently has four different Mac Pro Expansion (MPX) Modules that contain AMD Radeon Pro graphics processing units (GPUs). Radeon Pro MPX Modules can use slots 1-2 and slots 3-4, and you can install one or two of each module:

Radeon Pro 580X MPX Module: one module only
Radeon Pro W5700X MPX Module: one or two modules
Radeon Pro W5500X MPX Module: one or two modules
Radeon Pro Vega II MPX Module: one or two modules
Radeon Pro Vega II Duo MPX Module: one or two modules

You can use Radeon MPX Modules along with other third-party PCIe graphics cards. If you use Boot Camp, using a Radeon MPX Module and a third-party AMD graphics card isn't supported when your Mac is using Windows. Learn about using AMD graphics cards with Microsoft Windows on Mac Pro (2019).

Apple I/O card

Mac Pro comes with the Apple I/O card, which has two Thunderbolt 3 ports, two USB-A ports, and a 3.5mm headphone jack. The Apple I/O card comes preinstalled in slot 8 and can't be installed in another slot.

Third-party PCIe cards

Pci Vs Pci Express

You can install many different PCIe cards in your Mac Pro, such as fibre channel cards, fibre networking cards, and pro video and audio interface cards. The PCIe bus on your Mac Pro provides up to 300W auxillary power. If your PCIe card requires additional power, such as a GPU, use the Belkin Aux Power Cable.

Mac Pro supports the same GPUs that are supported by external graphics processors (eGPUs). If you use Boot Camp and want to install a NVIDIA card to use in Windows on your Mac, don't install the card in slot 2. Learn about using AMD graphics cards with Microsoft Windows on Mac Pro (2019).

Some older PCI cards might use 32-bit Option ROMs that aren't compatible with your Mac Pro. If you install a PCI card that uses 32-bit option ROMs, your Mac Pro might not start up correctly.

Afterburner

Afterburner is a hardware accelerator card made by Apple. Learn more about Afterburner.

RAID cards

If you want to add additional storage, you can install a third-party RAID card, such as a SAS RAID card, or you can install the Promise Pegasus R4i 32TB RAID MPX Module in one of the two MPX bays. If you use Boot Camp on your Mac, Windows doesn't support Apple software RAID volumes.
